Abracs Trade 230mm diamond blade for cutting concrete, brick, natural stone and tiles with a 9 inch angle grinder. A segmented general construction blade with a 10mm diamond segment and a strengthened core, built for extended life and a good cost per cut. The large diameter gives the depth to cut through block, kerb and paving in a single pass where a smaller blade would need cutting from both faces.
Wet or dry cutting Can be run dry on a handheld grinder or wet where dust suppression and longer blade life matter.
For masonry, not metal Diamond blades cut hard mineral materials. They are not for steel or other metals — if you need to cut metal, use one of our cutting discs instead.
Size 230mm diameter x 10mm segment x 22mm bore (9")
Brand Abracs Trade
Part number ABDD230M
Type Segmented, wet or dry cutting
Segment height 10mm
Core Strengthened steel core
Standard Manufactured to EN 13236
Maximum speed 6,600 RPM / 80 m/s
Materials Concrete, brick, block, natural stone and tiles
Uses Cutting block, kerb and paving to size, chasing and channelling, and deeper construction cuts a 115mm or 125mm blade cannot reach.
Fits Standard 22mm bore, fits most 9 inch angle grinders.
Also known as 9 inch diamond blade, 230mm diamond cutting disc, masonry cutting disc, segmented diamond disc or concrete cutting disc.
