4 Pin Automotive Relay - 24V 20A, Normally Open, With Bracket

4 Pin Automotive Relay (24V, Normally Open, with Bracket) — a high quality automotive relay designed for dependable switching in 24V vehicle electrical systems. Featuring a normally open contact, it is supplied with a detachable mounting bracket for secure and easy installation. Manufactured to original equipment standards, this relay is suitable for commercial vehicles, trucks, buses, plant machinery and other 24V applications.

Voltage
24V DC

Current rating
20A

Contact type
Normally open (NO)

Pins
4

Mounting
Detachable metal bracket included

Terminal type
Standard automotive spade terminals

Colour
Black

Suitable for
Trucks and commercial vehicles, buses and coaches, agricultural and construction machinery, plant equipment, general 24V electrical circuits

Cross reference numbers
Audi/Seat/Skoda/VAG/Volkswagen 183 951 253, Delphi SRB530, Durite 0-727-24, Ford 81DB 15K235 VA, Hella 4RA 003 510 057, Lucas SRB530, Mafco 425-1020, Scania 235940/243462, Woodauto RLY1002

Also known as a mini relay, 24V vehicle relay, or 4-pin bracket relay.
